Description
Details
Video Input: 16 Ch IP @ 160 Mbps
Video Output: HDMI up to 4K (3840 x 2160) / VGA up to 1080p
Max. Recording Resolution: Up to 8 MP (3840 x 2160)
Decoding Format: H.265 / H.264
Decoding Capability: 2 Ch @ 4K / 8 Ch @ 1080p
Max. Playback Resolution: Up to 8 MP (3840 x 2160)
Audio Channels In/Out: 1 / 1, RCA
Alarm Channels In/Out: 4 / 1
Built-in PoE: 16 Ch
Network: 10/100/1000 Mbps, 1 x RJ45
Storage: 2 x SATA up to 10 TB
Backup: 1 x USB 2.0, 1 x USB 3.0
Dimensions (W x D x H): 14.9 x 12.4 x 2.1
Rack Space: 1U
100 ~ 240V AC
SPECIFICATIONS
Audio / Video Input
IP Video Input
16 channels
Two-way Audio Input
1 channel, RCA
Network
Incoming Bandwidth
160 Mbps
Outgoing Bandwidth
64 Mbps
Remote Users
128
Protocols
P2P, UPnP, NTP, DHCP, PPPoE
Audio / Video Output
HDMI / VGA Output
HDMI: 4K (3840 x 2160 @ 30 fps), 1920 x 1080 @ 60 fps, 1920 x 1080 @ 50 fps, 1600 x 1200 @ 60 fps, 1280 x 1024 @ 60 fps, 1280 x 720 @ 60 fps, 1024 x 768 @ 60 fps
VGA: 1920 x 1080 @ 60 fps, 1920 x 1080 @ 50 fps, 1280 x 1024 @ 60 fps, 1280 x 720 @ 60 fps, 1024 x 768 @ 60 fps
Recording Resolution
8 / 6 / 5 / 4 / 3 MP; 1080p / 960p / 720p; D1 / 2CIF / CIF
Audio Output
1 ch, RCA
Synchronous Playback
16 ch
Corridor Mode Screen
3 / 4 / 5 / 7 / 9 / 10 / 12 / 16
Decoding
Decoding format
Ultra265 / H.265 / H.264
Live view / Playback
8 / 6 / 5 / 4 / 3 MP; 1080p / 960p / 720p; D1 / 2CIF / CIF
Capacity
2 x 4K @ 30 fps, 4 x 4 MP @ 30 fps, 5 x 3 MP @ 30 fps, 8 x 1080 @ 30 fps, 16 x 720 @ 30 fps
Hard Drive
SATA
2 x SATA interfaces
Capacity
Up to 10 TB for each disk
External Interface
Network Interface
1 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet Interface
USB Interface
Front panel: 1 x USB 2.0, Rear panel: 1 x USB 3.0
Alarm In
4 channels
Alarm Out
1 channel
PoE
Interface
16 independent 100 Mbps PoE network interfaces
Max Power
Max. 30 W for single port
Max. 240 W in total
Supported Standard
IEEE 802.3 af / at
General
Power Supply
(without HDD)
100 ~ 240 V AC
Power Consumption: ≤ 10 W
Operating Environment
14° to 131° F (-10° to 55° C), Humidity ≤ 90% RH (non-condensing)
Dimensions
(W x D x H)
14.9 x 12.4 x 2.1" (380 x 315 x 53 mm)
Weight
(without HDD)
≤ 5.29 lb (2.6 kg)
SKU IQVSN7216-P16
RECORDER TECHNOLOGY IP / NVR
RECORDER CASE 1U Case
RECORDER SERIES Pro-VS
RECORDER CHANNEL 16-Channel
